Siemens 6GK1901-0DB20-6AA0

Rayon Automation offers in-stock Siemens 6GK1901-0DB20-6AA0 connectors with built-in metal piercing (IDC) contact structure. Field engineers do not need to strip each twisted wire core when wiring. With the dedicated IE FC stripping tool, simply remove the outer sheath of the cable, mark it by color and insert it into the cable tray, and fasten the casing to simultaneously complete electrical contact, cable tension release and 360-degree shielding layer grounding. We have a wide range of model inventories. You can consult us for more models.

Product performance

In the industrial Ethernet topology, the enclosure of Siemens 6GK1901-0DB20-6AA0 has an overall protection rating of IP20, supports the CAT5e transmission standard, and has a data transmission rate of 100 Mbit/s. It meets the latency and packet loss rate requirements of PROFINET real-time communication. The contact resistance of the wiring contacts is extremely low, and the connector can operate stably within a wide temperature range of -40°C to +85°C and can withstand a maximum relative humidity of 95% (without condensation).

Technical Specifications

What are the differences from ordinary commercial-grade RJ45 plugs?

The housing of Siemens 6GK1901-0DB20-6AA0 is made of a sturdy all-metal die-cast zinc, which can isolate the strong electromagnetic radiation generated by industrial site frequency converters, servo drives and high-voltage switch cabinets. It is equipped with a metal clip inside, which ensures high performance. Even in an environment where the device vibrates frequently, it can still maintain a tight physical connection between the plug and the RJ45 female socket.

Application scenario

The Siemens 6GK1901-0DB20-6AA0 is used for PROFINET network connections of SCALANCE industrial switches, S7-1200/S7-1500 series PLCs, ET 200SP distributed IO modules, and SINAMICS frequency conversion drives. Typical industrial applications include wind turbine control cabinets, photovoltaic wafer production lines, robot picking workstations, and automated logistics picking systems.

How to maintain

The Siemens 6GK1901-0DB20-6AA0 plug is compact in structure and does not contain any vulnerable electronic components. If there is a physical link interruption or CRC message error in the network, engineers can check whether the clips are fully locked on the device's network port, or use a network cable tester to measure the continuity of pins 1, 2, 3, and 6 of the cable. If the contacts undergo physical deformation due to multiple plugging and unplugging, it is recommended to re-cut the wires and crimp them using a new 6GK1901-0DB20-6AA0 connector.

Related Models & Compatibility (Related Models and Compatibility)

6GK1901-0DB10-6AA0: 90-degree outlet IE FC RJ45 quick-connect plug

6GK1901-0DB30-6AA0:145 degree outlet IE FC RJ45 fast connection plug

6GK1901-1GA00: IE FC stripping tool (suitable for quickly stripping industrial Ethernet cables)

IE FC TP Standard Cable GP 2x2 (Green standard Industrial Ethernet cable)

Our shipment

Rayon Automation has a dedicated storage area for industrial control network spare parts. Customers will purchase various models through us. The goods of different models will be packed together and dispatched. Before the shipment, we will take photos and inform the customers. The goods will be delivered to the customers by air express.

FAQ：

Can 6GK1901-0DB20-6AA0 be used for ordinary household/commercial Cat6 network cables?

It is not recommended. The IDC piercing terminals inside the plug are designed for industrial-grade single-strand solid or thick-stranded FastConnect cables (such as AWG 22). The conductors of ordinary commercial network cables are too thin and may not be effectively clamped by the piercing terminals, which can easily lead to poor contact.

Does the shipped connector have original packaging and labels?

Yes, the Siemens original sealed plastic bag packaging and anti-counterfeiting labels issued by Rayon Automation are available for verification through the official channels.

How many connectors and matching cables are needed and what is the delivery cycle?

Rayon's standard stock products. Orders for regular quantities can be completed for packaging and shipment within 24-48 hours. For large-scale matching orders, our supply chain team can also complete the allocation and shipment within the shortest time and inform the customer of the time to reach an agreement.
