Schneider BMXP342020

As a professional Schneider BMXP342020 manufacturer, Hanhuiguan is your trustworthy partner. If you are looking for Schneider products, we especially provide you with the BMXP342020 processor module with extremely high cost performance, affordable price and quality assurance.

Send Inquiry

Product Description

As a professional Schneider BMXP342020 supplier, Hanhuiguan has served more than 50 countries around the world. For BMXP342020 processor module, we sincerely invite new and old customers to consult. We promise to provide you with complete and thoughtful service.

Product Parameters

Model	Schneider BMXP342020
Operating temperature range	-25°C to +55°C
Storage temperature range	-40°C to +85°C
Dimensions	110 x 140 x 30 mm
Weight	0.3 kg
Discrete I/O	1024 points
Analog I/O	256 points

Applications

The Schneider BMXP342020 is equipped with an NXP Cortex-A53 core with a main frequency of up to 750 MHz, has powerful computing power, and has built-in 4096 KB of memory, which is sufficient to cope with complex application requirements. Its interface configuration is rich and diverse, including an Ethernet interface (using an RJ45 connector) that supports Ethernet Modbus/TCP networks to ensure high-speed data transmission; a serial communication interface that is compatible with Modbus serial links (RS 232C/RS 485, 2-wire, non-isolated) and is suitable for character mode links; and a mini-B USB connector for easy programming and debugging, located on the front panel.

The front panel design of the BMXP342020 takes into account both user convenience and device safety. 8 LED indicators display the device status in real time, such as Ethernet activity (ETH ACT), operating status (RUN), and Ethernet status (ETH STS). There is a security screw on the front of the module to lock the module firmly in the slot, effectively preventing accidental movement and ensuring safe and stable operation of the device.

In terms of storage and data protection, the BMXP342020 comes standard with an SD (Secure Digital) flash card for backing up the RAM, programs, symbols, comments, and constant areas inside the processor module. When the PLC is turned off, the data is automatically backed up; after power is restored, the data recovery process is completely transparent to the user, ensuring data security and reliability.

The BMXP342020 is fully compatible with the Modicon M340 programmable logic controller (PLC) series and can be widely used in various industrial automation scenarios. At the same time, two packaging types (PCE and SO2) are provided to meet different installation requirements, providing users with flexible choices.
