Woodward DN3-PCI-1-E

As a professional supplier, we offer you this Woodward DN3-PCI-1-E. This is the very famous SST series product under the Woodward brand. People usually call it "DeviceNet PCI Communication Card" or "Scanning Card". Its role is extremely crucial. It is inserted into the PCI slot of your industrial control computer or dedicated controller, serving as the brain of the entire communication network, responsible for "scanning" the devices beneath, collecting the data from the frequency converters, servo drives, remote IO modules and other minions, and then transmitting it to the upper-level software. If your current project is lacking such a card to establish the data link, or if the old card suddenly breaks down due to lightning strike or aging, causing the entire line to stop, then come to us at Hanhui Guan. We have been deeply involved in the industrial communication spare parts business for many years, and we are very familiar with the temperament and characteristics of this product. We will definitely be able to help you solve the urgent problem.

Send Inquiry

Product Description

Hanhui Guan Company, as a professional supplier, has specially prepared a crucial connection component in the field of data communication for overseas industrial automation experts - the Woodward DN3-PCI-1-E DeviceNet interface card. When conducting upper-level machine monitoring or production line data collection, people often encounter a difficult problem: Industrial control computers want to directly communicate with the DeviceNet network at the equipment layer, but ordinary network cards simply cannot understand this industrial language. Hanhui Guan Company, as a professional spare parts supplier, recommends this high-performance board card that can transform ordinary computers into "industrial communication main stations" to everyone. The purpose is to help you easily break the barrier between equipment and computers, making data transmission as simple and reliable as connecting wires, and completely solving the problem of incompatible communication protocols.

Characteristics

This product fully demonstrates Woodward's expertise in manufacturing high precision equipment in terms of quality and craftsmanship. The design and manufacture of the product strictly follows international standards, and every detail is perfected to ensure that the product performs well in various application scenarios. First of all, Woodward utilizes top-quality materials and advanced manufacturing technologies to ensure the durability and reliability of its products. Whether dealing with harsh working environments or handling complex tasks, the DN3-PCI-1-E is able to consistently deliver stable performance.The Woodward DN3-PCI-1-E interface card is "compact" and "industrial". It uses a standard PCI short card structure, which is heavy in the hand and very textured. The most noticeable feature is the sturdy metal panel, which is designed to withstand harsh environments and effectively shield external electromagnetic interference. Under the baffle is a standard 5-pin open DeviceNet interface, which is especially convenient for field wiring. No special tools are needed, and the wire can be connected with a screwdriver. There are also two prominent LED indicators on the panel, in red and green, which allow the on-site technicians to quickly understand whether the card is running data or reporting a fault by looking at the lights. This is truly a thoughtful "little assistant" for the on-site technicians.

Performance

The performance of this Woodward DN3-PCI-1-E is truly "extremely robust". It supports both the master station (scanner) and slave station working modes of DeviceNet, which means it can not only control the devices below but also report data to other controllers, with extremely high flexibility. It has a very fast data refresh rate, supports up to 500K baud rates, and ensures that signals from sensors in the field are transmitted to the computer in near real time, without the delay that occurs when all the devices are stopped and the screen is still moving. The most crucial aspect is its stability. Even in an environment with many frequency converters and high electromagnetic noise in a factory, it can still reliably transmit data, rarely experiencing disconnections or packet loss issues.

Specification

Product Model	Woodward DN3-PCI-1-E
Board Dimensions	Standard PCI Short Card (Approx. 174mm x 69mm)
Bracket Height	120mm (Standard Full-Height Bracket)
Weight	Approx. 140g
Mounting Method	PCI Slot Insertion, Bracket Screw Fixed
Cable Interface	5-Pin Open-Style Pluggable Terminal Block
LED Indicators	Module Status / Network Status
Cooling Method	Natural Air Cooling (Fanless / Silent)
